Max. Output (1% THD):+29 dBu
THD+N (+26dBu, GAIN =40dB): 0.0004% typ.
Max.Input (no pad):+22dBu (+28dBu Output at min. gain)
Frequency Response (Gain = 40dB):1.5Hz to 600KHz (-3dB)
HPF:80Hz
Low Gain Range, preamp:6dB to 58dB
High Gain Range, preamp:18dB to 70dB
Input Impedance, preamp:5.5Kohm
Low Gain Range, DI:-14dB to 38dB
High Gain Range, DI: -2dB to 50dB
Input Impedance, DI:2.5Mohm
Instrument input (DI):IN and THRU, TS jacks (1/4”)
Dimensions:1.5"W x 5.25”H x 6.05D”
Weight:1.4 lbs.
Physical Configuration:per 500 series module specification
