Technical parameters
Frequency Band: UHF
Receiver: Dual Channel PCB Module Receiver
Frequency Range: 795-805 MHz
Frequency Stability: PLL
F/N Ratio: 80dB
P/N Ratio: 80dB
Audio Output: 1/4”, 3-pin XLR
Power:DC12V/400mA
Transmitter
Frequency Range: 614-814 MHz
Frequency Stability: PLL
Modulation Mode: FM
Adjustment Depth: 35 KHz (Max)
Transmitting Power: ≤10dBm
RF Squelch: >50dB
Battery: AA*2
Musical Instrument Input:Guitar
System
Audio Frequency Response: 50-16000Hz
S/N Ratio: >100dB
T.H.D: <0.8%
Operating Distance: 100M
