Microphone Inputs
• Dynamic Range (A-Weighted): 106dB
• SNR (A-weighted): -105.3dB
• Frequency Response: 20Hz - 20kHz +/- 0.1 dB
• THD+N: 0.001% (measured at 1kHz with a 20Hz/22kHz bandpass filter)
• Noise: EIN > 125dB (128dB analogue to digital) (measured at 60dB of gain with 150 Ohm termination (20Hz/22kHz bandpass filter)
• Maximum level (A-weighted): 8.6dBu at 1%
Line Inputs
• Dynamic Range (A-Weighted): 106.5dB
• SNR (A-weighted): -106dB
• Frequency Response: 20Hz - 20kHz +/- 0.1dB
• THD+N (A-Weighted): < 0.001% (measured with 0dBFS input and 22Hz/22kHz bandpass filter)
• Noise: -90dBu (22Hz/22kHz bandpass filter)
• Maximum level (A-weighted): 16.3dBu at 1%
Instrument Inputs
• Frequency Response: 20Hz - 20kHz +/- 0.1dB
• THD+N: 0.004% (measured with 0dBu input and 20Hz/22kHz bandpass filter)
• Noise: -87dBu (20Hz/22kHz bandpass filter)
Line level Outputs
• Dynamic Range (A-Weighted): 105dB
• SNR (A-weighted): -104.5dB
• THD+N: < 0.001% (measured with 0dBFS input and 22Hz/22kHz bandpass filter)
• Maximum level (A-weighted): 16.13dBu at 0.885%
Additional Conversion Performance
• Clock jitter < 250 picoseconds
• THD+N AMPL (A-weighted)= -107dBFS
