מרחק שידור קולט עד כ-30 מטרים.
ניתן לעבוד על שני המיקרופונים במקביל ללא שום הפרעה. נא לציי
Technical Specifications:
Receiver:
Carrier Wave Frequency Range: UHF 794~806 MHz.
Oscillation Mode: Quarts Controlled Fixed Frequency.
Carrier Wave Stability: 10 PPM.
Sensitivity: -105dB @ sinad=12dB.
S/N Ratio: >105dB.
T.H.D: <0.5% @ 1kHz.
Image Rejection: 85dB typical.
Squrious Rejection: 75dB typical.
Frequncey Responses: 40Hz ~ 18kHz.
Working Distance: 30 Meter.
Squelch Control: Dual-squelch circuit.
AF Output Impedance: 2.2KU.
Max. Output Level: Balance: 0-400mv, Unbalance: 0-200mv.
Display: LED.
Power Supply: External DC Power Supply, 0.35A, 12~18V DC.
Output Connectors: 2x XLR Balanced Socket & Unbalanced TRs 6.35mm Socket.
Dimensions: 250 x 142 x 45mm.
Weight: 0.87Kg.
Transmitter:
Transmitter Power: 3mW.
Squrious Emission: <40dB (with carrier).
Display: LED.
Battery Voltage: 2x 1.5V.
Battery Life: Up to 8 hours
