System | Built-in Crossover two way, full range active speaker |
Cabinet material | Polypropylene, Trapezoid |
Cabinet color | Black |
Speaker units | 12" x1(Bass - Mid) in Bass Reflex cabinet 1xØ44mm (High frequency Driver) on special Horn |
Horn Dispersion (HxV) | 90°x60° |
Frequency response (±3dB) | 54Hz-18KHz |
Frequency response (-10dB) | 43Hz-20KHz |
Speakers average efficiency (dB/1M) | 98dB |
Maximum Sound Level (dB/1M) | 128dB |
Level Adjust | Master (S3A) / Mic.+ Line + Master (S4A) |
Tone Control | ± 12dB (100KHz) –Bass, (5KHz) -Treble |
Output of Power Amplifier | 400W (Bass - Mid unit) + 100W (High frequency Driver) |
Amplifier Distortion (Max. THD + Noise) | Line-0.02%, Microphone-0.04% |
Speakers Full Range Power Handling | 300WRMS |
Input impedance | Line - 47KOhm, Microphone - 10KOhm |
Connector type | XLR 3P / COMBI in (S3A) + 6.3 & RCA in (S4A) |
Power supply | AC 230V/50Hz |
Dimension(WXDXH mm/Pcs) | 370X290X590mm |
Packaging Dimension(WXDXH mm/Pcs) | 430X375X645mm |
Net weight(kg/Pcs) | 9.3kg (S3A) / 17.28kg (S4A) |
Gross weight including packing(Kg/Pcs) | 11.5kg (S3A) / 18.72kg (S4A) |
