Specification MKII Elite

• Channel balance at 1 kHz

  1 dB

• Output voltage at 1 kHz, 5cm/sec

   8,5 mV

• Channel seperation at 1 kHz

   25 dB

• Channel seperation at 15 kHz

  15 dB

• Tracking ability at 315Hz at recommended tracking force

  100 μm

• Compliance, dynamic, lateral

  13 μm/mN

• Stylus tip radius

  r/R 8/18 μm

• Tracking force range

  2.0-4.0 g

• Tracking force, recommended

  3.0 g

• Tracking angle

   20°

• Internal impedance, DC resistance

   1.2 kOhm

• Recommended load impedance

  150-400 pF

• Cartridge colour

  Black/Gold

• Cartridge weight

  18.5 g

• Reccomended load resistance

  47 kOhm

• Internal inductance

  800 mH
